Asus Meilin ax88u加载2.5G USB网卡驱动

需要的文件有rtl8125.ko

在jffs创建drivers

mkdir /jffs/drivers/

1.启动脚本如下：

编辑 /jffs/scripts/init-start

#!/bin/sh

# Make sure the script is indeed invoked
touch /tmp/001-init-start
logger -t "rtl8156" "init-start: loading RTL8156 driver..."

# It's safe to `insmod` here, since `usbcore` has already been
# installed before `init-start` was called.
# init.c: sysinit() -> init_wl() ->
#         init-broadcom.c: eval("insmod", "usbcore");
insmod /jffs/drivers/r8152.ko

# Note `insmod r8152.ko` must be executed before `cdc_ncm` module
# is loaded into kernel. Otherwise `cdc_ncm` will take control
# of the USB 2.5GbE adapter.
# If `r8152.ko` can't be loaded before `cdc_ncm`, then you should
# `rmmod cdc_ncm`,` insmod r8152.ko` and `insmod cdc_ncm`
# (remember to rm/insmod modules depending on `cdc_ncm` first)

logger -t "rtl8156" "init-start: all done"
date >> /tmp/001-init-start

2.配置脚本如下：

编辑 /jffs/scripts/services-start

#!/bin/sh

# Make sure the script is indeed invoked
touch /tmp/001-services-start
logger -t "rtl8156" "services-start: setting up eth8..."

# Update nvram variables
nvram set br0_ifnames="$(nvram get br0_ifnames) eth8"
nvram set lan_ifnames="$(nvram get lan_ifnames) eth8"
nvram set wired_ifnames="$(nvram get wired_ifnames) eth8"

# Add eth8 into br0
brctl addif br0 eth8

# Set TX queue length to 2500 on eth8 and bring it up
ifconfig eth8 txqueuelen 2500 allmulti up

# Enable USB scatter/gather on eth8
echo enable > /sys/class/net/eth8/rtl_adv/sg_en

# Enable RPS (Receive Packet Steering) on eth8.
# Since AX88U has four cores, we set it to 'f'
echo f > /sys/class/net/eth8/queues/rx-0/rps_cpus

logger -t "rtl8156" "services-start: all done"
date >> /tmp/001-services-start
